3KL7141-3CA00
3KL7141-3CA00 SIEMENS Switch disconnector with fuses 3x 315A W
$0.00USD
3019 in stock
Key Specifications
:Value
EAN:Not available
UPC:Not available
Group Code:P360
Supplier Information
SIEMENS
Products: 367174
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Value | |
| EAN | Not available |
| UPC | Not available |
| Group Code | P360 |
| Price Group | 12S |
| Metal Factor | None |
| Product Group | 5855 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Quantity Unit | 1 Piece |
| Commodity Code | 85365080 |
| Product family | Not available |
| Net Weight (kg) | 6,600 Kg |
| Country of origin | Italy |
| LKZ_FDB/ CatalogID | LV10.1 |
| Packaging Quantity | 1 |
| Packaging Dimension | Not available |
| Product Description | Switch disconnector with fuses 3x 315A W |
| Product Lifecycle (PLM) | PM300:Active Product |
| Interlockable (EF006281) | - |
| Export Control Regulations | ECCN : N / AL : N |
| Number of poles (EF001391) | 3 |
| Standard lead time ex-works | 30 Day/Days |
| Surcharge for Raw Materials | None |
| Package size unit of measure | Not available |
| Number of switches (EF005586) | - |
| Device construction (EF008240) | - |
| Product Dimensions (W x L x H) | Not available |
| Motor drive optional (EF007386) | - |
| Colour control element (EF007167) | - |
| Motor drive integrated (EF006697) | false |
| Version as main switch (EF006981) | - |
| Rated operating voltage (EF001435) | - |
| Type of control element (EF006976) | - |
| Switching power at 400 V (EF009166) | - |
| Version as safety switch (EF006985) | true |
| Voltage release optional (EF007491) | - |
| Article Number (Market Facing Number) | 3KL7141-3CA00 |
| Rated permanent current Iu (EF001389) | 315.0 |
| Degree of protection (NEMA) (EF011959) | - |
| Suitable for floor mounting (EF007243) | FALSE |
| Version as reversing switch (EF009408) | - |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
| Max. rated operation voltage Ue AC (EF007355) | 690 |
| Suitable for front mounting 4-hole (EF007247) | - |
| Suitable for front mounting centre (EF007248) | - |
| Suitable for intermediate mounting (EF007264) | - |
| Rated operation power at AC-3, 400 V (EF001364) | - |
| Degree of protection (IP), front side (EF003118) | IP00 |
| Rated operation power at AC-23, 400 V (EF007027) | - |
| Rated short-time withstand current lcw (EF007050) | - |
| Version as emergency stop installation (EF006959) | - |
| Version as maintenance-/service switch (EF006986) | - |
| Rated permanent current at AC-21, 400 V (EF009165) | - |
| Rated permanent current at AC-23, 400 V (EF011777) | - |
| Conditioned rated short-circuit current Iq (EF001444) | - |
| Suitable for distribution board installation (EF007262) | - |
| Type of electrical connection of main circuit (EF006819) | Rail connection |
| Number of auxiliary contacts as change-over contact (EF003531) | - |
| Number of auxiliary contacts as normally open contact (EF001376) | - |
| Number of auxiliary contacts as normally closed contact (EF001377) | - |
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 |
| REACH Art. 33 Duty to inform according to the current list of candidates | Reach InformationThere is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly. |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
