302369
302369 EATON ELECTRIC FRBMM-B16/2/003-A-120. RCD/MCB comb. switch, 16A, 30mA, miniature circuit-br. type B t..
$0.00USD
4071 in stock
Key Specifications
Feature Name:Feature Value
Frequency (EF005455):50/60 Hz
Voltage type (EF000187):AC
Rated current (EF000227):16 A
Supplier Information
Products: 0
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Feature Name | Feature Value |
| Frequency (EF005455) | 50/60 Hz |
| Voltage type (EF000187) | AC |
| Rated current (EF000227) | 16 A |
| Rated voltage (EF000228) | 120 V |
| Built-in depth (EF000218) | 75.5 mm |
| Pollution degree (EF002570) | 2 |
| Rated fault current (EF002358) | 0.03 A |
| Leakage current type (EF002560) | A |
| Over voltage category (EF002569) | 3 |
| Current limiting class (EF002568) | 3 |
| Release characteristic (EF000889) | B |
| Surge current capacity (EF002564) | 0.25 kA |
| Number of poles (total) (EF008618) | 2 |
| With interlocking device (EF007385) | No |
| Degree of protection (IP) (EF005474) | IP20 |
| Number of protected poles (EF005548) | 2 |
| Rated insulation voltage Ui (EF001366) | 500 V |
| Disconnection characteristic (EF012587) | Undelayed |
| Anti-nuisance tripping version (EF009497) | No |
| Width in number of modular spacings (EF002950) | 2 |
| Ambient temperature during operating (EF007515) | -25 °C |
| Rated impulse withstand voltage Uimp (EF011980) | 4 kV |
| Concurrently switching neutral conductor (EF005997) | No |
| Connectable conductor cross section solid-core (EF007337) | 1 mm² |
| Connectable conductor cross section multi-wired (EF007343) | 1 mm² |
| Rated short-circuit breaking capacity according to EN 61009 (EF012628) | 10 kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 (EF006065) | 0 kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 (EF011981) | 10 kA |
Product Description
High-quality residual current device/miniature circuit breaker combination, line voltage-independent, contact position indicator red - green, terminal rear plug protection, tri-stable slide catch - en
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
