3000-16513-3100022
3000-16513-3100022 MURRELEKTRONIK MIRO 6.2 PLUGGABLE COMPL.MODULE OUTPUT RELAY
$0.00USD
4394 in stock
Key Specifications
EAN:4048879021326
AC-12:6 A (24/110/230 V AC)
AC-15:3 A (24/110 V AC); 1.5 A (230 V AC)
DC-13:1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC)
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879021326 |
| AC-12 | 6 A (24/110/230 V AC) |
| AC-15 | 3 A (24/110 V AC); 1.5 A (230 V AC) |
| DC-13 | 1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC) |
| eClass | 27371601 |
| Art.No.: | 3000-16513-3100022 |
| Protection | IP20 |
| LED display | LED (green) |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable (EN 60715) |
| Contact material | Ag Sn O2 |
| Min. load current | 100 mA |
| Switching voltage | max. 250 V AC/30 V DC |
| Temperature range | -25...+60 °C |
| country of origin | CN |
| Mech./ elect. life | 10 000 000 switching cycles (NO) 30 000; (NC) 10 000, load dependent |
| Switching frequency | max. 10 Hz |
| Alternative product: | Product Comparison1 NO/NC contact60 V AC/DCSpring clamp terminalsInputConnection voltage - current60 V AC/DC (43.5...72 V AC/DC) - 7 mALED displayLED (green)Utilization categoryAC-126 A (24/110/230 V AC)AC-153 A (24/110 V AC); 1.5 A (230 V AC)DC-131 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC)General dataTest isolation voltage250 VMech./ elect. life10 000 000 switching cycles (NO) 30 000; (NC) 10 000, load dependentProtectionIP20Mounting methodDIN-rail mountable (EN 60715)Dimensions H × W × D93×6.2×75.6 mmTemperature range-25...+60 °COutputSwitching voltagemax. 250 V AC/30 V DCSwitching current per outputmax. 6 AMin. load current100 mAPower rating (voltage dependent)max. 1 500 VA/180 WSwitching frequencymax. 10 HzContact materialAg Sn O2Energize/release/contact bounce time8/4/- msCommercial datacountry of originCNcustoms tariff number85364900EAN4048879021326eClass27371601Packaging unit1 |
| customs tariff number | 85364900 |
| Dimensions H × W × D | 93×6.2×75.6 mm |
| Test isolation voltage | 250 V |
| Connection voltage - current | 60 V AC/DC (43.5...72 V AC/DC) - 7 mA |
| Switching current per output | max. 6 A |
| Power rating (voltage dependent) | max. 1 500 VA/180 W |
| Energize/release/contact bounce time | 8/4/- ms |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
