3000-16013-3100020
3000-16013-3100020 MURRELEKTRONIK MIRO 6.2 PLUGGABLE COMPL.MODULE OUTPUT RELAY
$0.00USD
4736 in stock
Key Specifications
EAN:4048879021432
AC-12:6 A (24/110/230 V AC)
AC-15:3 A (24/110 V AC); 1.5 A (230 V AC)
DC-13:1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC)
Supplier Information
MURRELEKTRONIK
Products: 57918
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 4048879021432 |
| AC-12 | 6 A (24/110/230 V AC) |
| AC-15 | 3 A (24/110 V AC); 1.5 A (230 V AC) |
| DC-13 | 1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC) |
| eClass | 27371601 |
| Protection | IP20 |
| LED display | LED (green) |
| Packaging unit | 1 |
| Mounting method | DIN-rail mountable (EN 60715) |
| Contact material | Ag Sn O2 |
| Min. load current | 100 mA |
| Switching voltage | max. 250 V AC/30 V DC |
| Temperature range | -25...+60 °C |
| country of origin | CN |
| Dimensions H×W×D | 93×6.2×75.6 mm |
| Mech./ elect. life | 10 000 000 switching cycles (NO) 30 000; (NC) 10 000, load dependent |
| Switching frequency | max. 10 Hz |
| customs tariff number | 85364900 |
| Test isolation voltage | 250 V |
| Connection voltage - current | 24 V AC/DC (19.2...28.8 V AC/DC) - 12 mA |
| Switching current per output | max. 6 A |
| Power rating (voltage dependent) | max. 1500 VA/180 W |
| Energize/release/contact bounce time | 8/4/- ms |
Product Description
MIRO 6.2 PLUGGABLE COMPL.MODULE OUTPUT RELAYIN: 24 VAC/DC - OUT: 250 VAC/30VDC / 6 A
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
