2CCS893001R0634
S803N-C63 2CCS893001R0634 ABB S803N-C63 High Performance Circuit Breaker
$0.00USD
3865 in stock
Key Specifications
Remarks: (Dimensions):Connection from top and bottomConnecting with CU onlyIP40 in enclosure with coverCage terminal with captive screw
Customs Tariff Number::85362020
Minimum Order Quantity::1 piece
Standards: (Dimensions):IEC/EN 60947-2IEC/EN 60898-1
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Remarks: (Dimensions) | Connection from top and bottomConnecting with CU onlyIP40 in enclosure with coverCage terminal with captive screw |
| Customs Tariff Number: | 85362020 |
| Minimum Order Quantity: | 1 piece |
| Standards: (Dimensions) | IEC/EN 60947-2IEC/EN 60898-1 |
| Power Loss: (Dimensions) | at Rated Operating Conditions per Pole 6.4 W |
| RoHS Status: (Technical) | Following EU Directive 2011/65/EU |
| Terminal Type: (Dimensions) | Screw Terminals |
| Dimension Diagram: (Ordering) | 2CCC413003C0201 |
| Number of Poles: (Dimensions) | 3 |
| Housing Material: (Dimensions) | Insulation group I, RAL 7035 |
| Pollution Degree: (Dimensions) | 3 |
| ETIM 4: (Container Information) | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 5: (Container Information) | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 6: (Container Information) | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 7: (Container Information) | EC000042 - Miniature circuit breaker (MCB) |
| Mounting Position: (Dimensions) | Any |
| Tightening Torque: (Dimensions) | 3.5 N·m31 in·lb |
| Rated Current (In): (Dimensions) | 63 A |
| Connecting Capacity: (Dimensions) | Stranded 1 ... 50 mm²Flexible 1 ... 70 mm² |
| E-nummer: (Container Information) | 2101538 |
| Operational Voltage: (Dimensions) | Maximum 230/400 V ACMinimum 12 V AC |
| Rated Frequency (f): (Dimensions) | 50 / 60 Hz |
| RoHS Information: (Environmental) | 2CCC413008D0206 |
| Degree of Protection: (Dimensions) | acc. to IEC 60529 IP20 |
| Electrical Endurance: (Dimensions) | 6000 cycle |
| Mounting on DIN Rail: (Dimensions) | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| Overvoltage Category: (Dimensions) | IV |
| Energy Limiting Class: (Dimensions) | 3 |
| Ambient Air Temperature: (Technical) | Operation -25 ... +60 °CStorage -40 ... +70 °C |
| Instructions and Manuals: (Ordering) | 2CCC413016M0008 |
| Environmental Conditions: (Technical) | Damp Heat Cyclic acc. to IEC 60068-2-30 12+12 cycleDamp Heat Cyclic acc. to IEC 60068-2-30 55°C @ 90-96%Damp Heat Cyclic acc. to IEC 60068-2-30 25°C @ 90-100%Dry Heat Test B acc. to IEC 60068-2-2 16 hour @ 55 °CDry Heat Test B acc. to IEC 60068-2-2 2 hour @ 70 °C |
| Tripping Characteristic: (Dimensions) | C |
| Product Net Width: (Popular Downloads) | 81 mm |
| Recommended Screw Driver: (Dimensions) | Pozidriv 2 |
| Product Net Height: (Popular Downloads) | 95 mm |
| Product Net Weight: (Popular Downloads) | 735 g |
| Rated Operational Voltage: (Dimensions) | 400/690 V AC375 V DC |
| Contact Position Indication: (Dimensions) | ON / OFF / TRIP |
| Instructions and Manuals: (Environmental) | 2CCC413016M0008 |
| Environmental Information: (Environmental) | 2CCY413207D0203 |
| Mechanical Endurance (Nendu): (Dimensions) | 4000 cycle |
| Rated Insulation Voltage (Ui): (Dimensions) | 690 V AC |
| Data Sheet, Technical Information: (Ordering) | 2CCC413003C0208 |
| Declaration of Conformity - CE: (Environmental) | 2CCC413016D0601 |
| Product Net Depth / Length: (Popular Downloads) | 82.5 mm |
| Rated Short-Circuit Capacity (Icn): (Dimensions) | (230 / 400 V AC) 20 kA |
| Object Classification Code: (Container Information) | F |
| Rated Impulse Withstand Voltage (Uimp): (Dimensions) | 8 kV |
| Resistance to Shock acc. to IEC 60068-2-27: (Technical) | 5 g30 ms |
| Resistance to Vibrations acc. to IEC 60068-2-6: (Technical) | 2 - 13.2 Hz / 1mm13.2 - 100Hz / 0.7gwith load 100% x Ie |
| Rated Service Short-Circuit Breaking Capacity (Ics): (Dimensions) | (240 / 415 V AC) 30 kA(254 / 440 V AC) 15 kA(400 / 690 V AC) 3 kA(125 V DC) 20 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu): (Dimensions) | (240 / 415 V AC) 36 kA(254 / 440 V AC) 20 kA(400 / 690 V AC) 4.5 kA(375 V DC) 20 kA |
| Package Level 1 EAN: (Certificates and Declarations (Document Number)) | 7612271204600 |
| Package Level 1 Units: (Certificates and Declarations (Document Number)) | 1 piece |
| Package Level 1 Width: (Certificates and Declarations (Document Number)) | 105 mm |
| Package Level 2 Units: (Certificates and Declarations (Document Number)) | 1 |
| Package Level 1 Height: (Certificates and Declarations (Document Number)) | 99 mm |
| Package Level 1 Gross Weight: (Certificates and Declarations (Document Number)) | 770 g |
| Package Level 1 Depth / Length: (Certificates and Declarations (Document Number)) | 86 mm |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
