In Stock Hot Product
2512+068
2512+068 DANFOSS REFRIGERATION LLG 590 SF Liquid level glasses
$0.00USD
3245 in stock
Key Specifications
EAN ():5702428200165
Type ():LLG 590 SF
Volume ():41.262 Liter
Approval ():EAC
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN () | 5702428200165 |
| Type () | LLG 590 SF |
| Volume () | 41.262 Liter |
| Approval () | EAC |
| Equipment () | SNV-ST and Sight adapter |
| Net weight () | 18.47 Kg |
| Combined by () | LLG 185 + LLG 335 |
| Fluid Group () | 1 |
| Gross weight () | 20.21 Kg |
| PED category () | Art. 3, par. 3 |
| Refrigerants () | R717 |
| Product group () | Sight glasses |
| Packing format () | Single pack |
| EU RoHS compliance () | No - out of scope |
| Product description () | Liquid level glasses |
| Product Name Description () | Sight glass |
| Max. Working Pressure [bar] () | 25 bar |
| Quantity per packing format () | 1 pc |
| Max. Working Pressure [psig] () | 363 psig |
| Temperature range [°C] [max] () | 30 °C |
| Temperature range [°C] [min] () | -50 °C |
| Temperature range [°F] [max] () | 86 °F |
| Temperature range [°F] [min] () | -58 °F |
| REACH Candidate List substances () | Lead (CAS no. 7439-92-1) |
| In scope of WEEE and contain batteries () | No |
Product Description
Sight glass, LLG 590 SF
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Product Type: LLG 590 SF
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
