1SDA067866R1
1SDA067866R1 ABB XT2H 160 Ekip I In 160A 3p F F
$0.00USD
4791 in stock
Key Specifications
EAN::8015644017620
Customs Tariff Number::85362090
Minimum Order Quantity::1 piece
Product Net Width: (Ordering):90 mm
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN: | 8015644017620 |
| Customs Tariff Number: | 85362090 |
| Minimum Order Quantity: | 1 piece |
| Product Net Width: (Ordering) | 90 mm |
| Product Net Height: (Ordering) | 130 mm |
| Product Net Weight: (Ordering) | 1,12 kg |
| Version: (Container Information) | F |
| Package Level 1 EAN: (Dimensions) | 8015644017620 |
| Sub-type: (Container Information) | XT2 |
| Standards: (Container Information) | IEC |
| Package Level 1 Units: (Dimensions) | 1 piece |
| Package Level 1 Width: (Dimensions) | 130 mm |
| Package Level 1 Height: (Dimensions) | 208 mm |
| Current Type: (Container Information) | AC |
| Opening Time: (Container Information) | CB with SOR 15 msCB with UVR 15 ms |
| Product Name: (Container Information) | Moulded Case Circuit Breaker |
| Product Type: (Container Information) | CB |
| Release Type: (Container Information) | EL |
| Product Net Depth / Length: (Ordering) | 82,5 mm |
| Order Multiple: (Container Information) | 1 piece |
| GL Certificate: (Additional Information) | 1SDL000163R0093 |
| LR Certificate: (Additional Information) | 1SDL000163R0100 |
| Number of Poles: (Container Information) | 3 |
| Package Level 1 Gross Weight: (Dimensions) | 1,22 kg |
| Product Main Type: (Container Information) | SACE Tmax XT |
| Rated Current (In): (Container Information) | 160 A |
| Rated Voltage (Ur): (Container Information) | 690 V |
| Package Level 1 Depth / Length: (Dimensions) | 145 mm |
| Rated Frequency (f): (Container Information) | 50 / 60 Hz |
| Electrical Durability: (Container Information) | 120 cycles per hour8000 cycle |
| Mechanical Durability: (Container Information) | Nr. Operations 240 cycles per hourNr. Operations 25000 cycle |
| Terminal Connection Type: (Container Information) | Fixed Circuit-BreakersFront |
| Instructions and Manuals: (Additional Information) | 1SDH000721R0001 |
| Rated Operational Voltage: (Container Information) | 690 V AC |
| Environmental Information: (Additional Information) | 1SDL000190R0001 |
| Rated Insulation Voltage (Ui): (Container Information) | 1000 V |
| Declaration of Conformity - CE: (Additional Information) | 9AKK106713A5901 |
| ETIM 4: (Certificates and Declarations (Document Number)) | EC000228 - Power circuit-breaker for trafo/generator/installation prot. |
| ETIM 5: (Certificates and Declarations (Document Number)) | EC000228 - Power circuit-breaker for trafo/generator/installation prot. |
| ETIM 6: (Certificates and Declarations (Document Number)) | EC000228 - Power circuit-breaker for trafo/generator/installation prot. |
| ETIM 7: (Certificates and Declarations (Document Number)) | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Rated Uninterrupted Current (Iu): (Container Information) | 160 A |
| UNSPSC: (Certificates and Declarations (Document Number)) | 39120000 |
| Data Sheet, Technical Information: (Additional Information) | 1SDC210033D0204 |
| Circuit Breaker Type to be Associated: (Container Information) | Power Distribution |
| Rated Impulse Withstand Voltage (Uimp): (Container Information) | 8 kV |
| WEEE Category: (Certificates and Declarations (Document Number)) | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Rated Service Short-Circuit Breaking Capacity (Ics): (Container Information) | (220 V AC) 100 kA(230 V AC) 100 kA(240 V AC) 100 kA(380 V AC) 70 kA(415 V AC) 70 kA(440 V AC) 65 kA(500 V AC) 50 kA(525 V AC) 30 kA(690 V AC) 15 kA |
| Object Classification Code: (Certificates and Declarations (Document Number)) | Q |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu): (Container Information) | (220 V AC) 100 kA(230 V AC) 100 kA(240 V AC) 100 kA(380 V AC) 70 kA(415 V AC) 70 kA(440 V AC) 65 kA(500 V AC) 50 kA(525 V AC) 30 kA(690 V AC) 15 kA |
