In Stock Hot Product
1SDA059677R1
1SDA059677R1 ABB E6 W FP 3p VR-VR new
$0.00USD
3445 in stock
Key Specifications
:Rear flat Vertical
EAN:8015644621018
ETIM 7:EC002043 - Chassis part power circuit breaker
ETIM 8:EC002043 - Chassis part power circuit breaker
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Rear flat Vertical | |
| EAN | 8015644621018 |
| ETIM 7 | EC002043 - Chassis part power circuit breaker |
| ETIM 8 | EC002043 - Chassis part power circuit breaker |
| Version | WFP |
| Sub-type | E6 |
| Standards | IEC |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Current Type | AC |
| Product Name | Fixed Part |
| Product Type | Fixed Part |
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) |
| Number of Poles | 3 |
| RoHS Information | 9AKK108466A1424 |
| Product Main Type | SACE Emax |
| Product Net Width | 810 mm |
| REACH Declaration | 9AKK108466A1425 |
| Product Net Height | 461 mm |
| Product Net Weight | 70 kg |
| Rated Voltage (Ur) | 690 V |
| Package Level 1 EAN | 8015644609139 |
| Customs Tariff Number | 85389099 |
| Package Level 1 Units | 1 piece |
| Minimum Order Quantity | 1 piece |
| Instructions and Manuals | 1SDH000460R0002 |
| Terminal Connection Type | Withdrawable Circuit-Breakers |
| Environmental Information | 1SDL000142R0 |
| Object Classification Code | Q |
| Product Net Depth / Length | 396.5 mm |
| Package Level 1 Gross Weight | 92 kg |
| Declaration of Conformity - CE | 1SDL000165R0017 |
| Rated Uninterrupted Current (Iu) | 6300 A |
| Data Sheet, Technical Information | 1SDC200006D0209 |
| Conflict Minerals Reporting Template (CMRT) | Document availability on demand |
Product Description
W TER FIXED BASE. VR-VR 3P - E6
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
