1SDA054757R1
1SDA054757R1 ABB T5 400 W FP 3p HR
$0.00USD
4314 in stock
Key Specifications
:750 V DC
EAN:8015644558789
Device:Fixed Part
ETIM 7:EC002043 - Chassis part power circuit breaker
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| 750 V DC | |
| EAN | 8015644558789 |
| Device | Fixed Part |
| ETIM 7 | EC002043 - Chassis part power circuit breaker |
| ETIM 8 | EC002043 - Chassis part power circuit breaker |
| ETIM 9 | EC002043 - Chassis part power circuit breaker |
| UNSPSC | 39121100 |
| eClass | V11.1 : 27370422 |
| Version | W |
| Sub-type | T5 |
| Standards | IEC |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Product Name | Accessory |
| Product Type | Fixed Part |
| Suitable For | T5 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Number of Poles | 3 |
| RoHS Information | 9AKK108466A1424 |
| Product Main Type | Accessories for Tmax T |
| Product Net Width | 171 mm |
| REACH Declaration | 9AKK108466A1425 |
| E-Number (Finland) | 3655583 |
| Product Net Height | 209 mm |
| Product Net Weight | 2.9 kg |
| Package Level 1 EAN | 8015644558789 |
| Customs Tariff Number | 85389099 |
| Package Level 1 Units | 1 piece |
| Package Level 1 Width | 228 mm |
| Minimum Order Quantity | 1 piece |
| Package Level 1 Height | 228 mm |
| Instructions and Manuals | 1SDH000436R0812 |
| Order Code US and Canada | KT5WFHR |
| Terminal Connection Type | Withdrawable Circuit-Breakers |
| Environmental Information | 9AKK108467A6707 |
| Rated Operational Voltage | 690 V AC |
| Object Classification Code | Q |
| Product Net Depth / Length | 50 mm |
| Suitable for Product Class | Moulded Case Circuit Breakers |
| Package Level 1 Gross Weight | 3.2 kg |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| Package Level 1 Depth / Length | 344 mm |
| Rated Uninterrupted Current (Iu) | 400 A |
| Data Sheet, Technical Information | 1SDC210015D0208 |
| Instructions and Manuals (Part 2) | ITSCE-RH0100001 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Test Voltage at Industrial Frequency for 1 Minute | not applicable V |
Product Description
W TERM FIXED PART. HR 3P - T5 400
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
