1SCA125150R1001
1SCA125150R1001 ABB Int. BOXED DC disconnector OTDCP16SA12M
$0.00USD
4968 in stock
Key Specifications
ETIM 7:EC000216 - Switch disconnector
ETIM 8:EC000216 - Switch disconnector
ETIM 9:EC000216 - Switch disconnector (low voltage)
eClass:V11.1 : 27371403
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| ETIM 7 | EC000216 - Switch disconnector |
| ETIM 8 | EC000216 - Switch disconnector |
| ETIM 9 | EC000216 - Switch disconnector (low voltage) |
| eClass | V11.1 : 27371403 |
| Standards | IEC 60947-1, -3 |
| Power Loss | at Rated Operating Conditions per Pole 0.15 W |
| Handle Type | Selector handle |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Handle Color | Red / Yellow |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| BV Certificate | 1SCC340018D0204 |
| Number of Poles | 3 |
| Pollution Degree | 3 |
| RoHS Information | 1SCC301239D0201 |
| Country of Origin | Finland (FI) |
| E-Number (Norway) | 1414582 |
| Product Net Width | 95 mm |
| REACH Declaration | 1SCC301240D0201 |
| Special Functions | Solar |
| E-Number (Finland) | 3601746 |
| Enclosure Material | Plastic |
| Product Net Height | 150 mm |
| Product Net Weight | 0.59 kg |
| Mechanical Drawings | OTDCK159595SM20.stp |
| Package Level 1 EAN | 6417019554075 |
| Cable Entry Position | Up/Down |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Customs Tariff Number | 85365080 |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 142 mm |
| Cable Outlets Per Side | 2xM20 / 2xM20 |
| Minimum Order Quantity | 1 piece |
| Package Level 1 Height | 108 mm |
| Instructions and Manuals | 1SCC340027M0002 |
| Rated Operational Voltage | Main Circuit 1000 V |
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Object Classification Code | Q |
| Product Net Depth / Length | 95 mm |
| Package Level 1 Gross Weight | 0.7 kg |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 1000 V |
| Declaration of Conformity - CE | 1SCC340003D2704 |
| Package Level 1 Depth / Length | 167 mm |
| Connecting Capacity Main Circuit | Screw Clamp 2.5…16 mm² |
| Data Sheet, Technical Information | 1SCC340015C0201 |
| Conventional Thermal Current (Ithe) | Fully Enclosed 16 A |
| Toxic Substances Control Act - TSCA | 1SCC301321D0201 |
| Rated Operational Current DC-21B (Ie) | (1000 V) 16 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Short-Circuit Making Capacity (Icm) | (690 V AC) 0.71 kA |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 0.5 kA |
Product Description
OTDCP16SA12M Enclosed solar switch
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
