1SBN010040R1222
1SBN010040R1222 ABB CA5-22N Auxiliary Contact Block
$0.00USD
3937 in stock
Key Specifications
:(690 V) 2 A
ETIM 4:EC002498 - Accessories for low-voltage switch technology
ETIM 5:EC002498 - Accessories for low-voltage switch technology
ETIM 6:EC000041 - Auxiliary contact block
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| (690 V) 2 A | |
| ETIM 4 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 5 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 6 | EC000041 - Auxiliary contact block |
| ETIM 7 | EC000041 - Auxiliary contact block |
| ETIM 8 | EC000041 - Auxiliary contact block |
| UNSPSC | 39121522 |
| eClass | V11.0 : 27371302 |
| RoHS Status | Following EU Directive 2011/65/EU |
| Suitable For | N22E |
| Terminal Type | Screw Terminals |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| CB Certificate | CB_SE_62119A1 |
| UL Certificate | UL_071301E48139 |
| WEEE B2C / B2B | Business To Business |
| CCC Certificate | CCC_2015010304800518 |
| CQC Certificate | CQC2015010304800518 |
| CSA Certificate | CSA_1033838 |
| EAC Certificate | EAC_RU C-FR ME77 B03391 |
| GOST Certificate | GOST_POCCFRME77B07174 |
| RINA Certificate | RINA_ELE172319XG001 |
| RoHS Information | 2CMT2021-006277 |
| Product Net Width | 43 mm |
| REACH Declaration | 2CMT2021-006202 |
| DNV GL Certificate | DNV_GL_TAE00001UT |
| E-Number (Finland) | 3709193 |
| Product Net Height | 47 mm |
| Product Net Weight | 0.06 kg |
| Package Level 1 EAN | 3471522121189 |
| Rated Frequency (f) | Auxiliary Circuit 50 / 60 Hz |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20 |
| Customs Tariff Number | 85389099 |
| Mechanical Durability | 10 million |
| Package Level 1 Units | 2 piece |
| Package Level 1 Width | 65 mm |
| Package Level 2 Units | box 200 piece |
| Package Level 2 Width | 300 mm |
| Package Level 3 Units | 3600 piece |
| Minimum Order Quantity | 2 piece |
| Package Level 1 Height | 43 mm |
| Package Level 2 Height | 308 mm |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Instructions and Manuals | 1SBC101012M5501 |
| Rated Operational Voltage | Auxiliary Circuit 690 V |
| Object Classification Code | K |
| Product Net Depth / Length | 39 mm |
| Package Level 1 Gross Weight | 0.12 kg |
| Package Level 2 Gross Weight | 12 kg |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 690 V |
| Declaration of Conformity - CE | 1SBD250809U1000 |
| Package Level 1 Depth / Length | 129.5 mm |
| Package Level 2 Depth / Length | 245 mm |
| Declaration of Conformity - CCC | 2020980304001627 |
| Number of Auxiliary Contacts NC | 2 |
| Number of Auxiliary Contacts NO | 2 |
| Declaration of Conformity - UKCA | 1SBD250826U1000 |
| Short-Circuit Protective Devices | Auxiliary Circuit - gG Type Fuses 10 A |
| Data Sheet, Technical Information | 1SBC100122C0202_Ch04 |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block |
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W |
| Maximum Electrical Switching Frequency | 1200 cycles per hour |
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 0.1 s 140 A |
Product Description
CA5-22N AUX Contact. for cont.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
