1SAE351111R0140
ESB63-40N-01 1SAE351111R0140 ABB Installation contactor 4NO 24AC/DC
$0.00USD
4585 in stock
Key Specifications
Package Level 1 EAN::4013614525278
Customs Tariff Number::85365080
Minimum Order Quantity::1 piece
Standards: (Dimensions):IEC/EN 60947-1IEC/EN 60947-4-1IEC/EN 61095UL 60947-1UL 60947-4-1
Supplier Information
ABB
Products: 44170
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Package Level 1 EAN: | 4013614525278 |
| Customs Tariff Number: | 85365080 |
| Minimum Order Quantity: | 1 piece |
| Standards: (Dimensions) | IEC/EN 60947-1IEC/EN 60947-4-1IEC/EN 61095UL 60947-1UL 60947-4-1 |
| Number of Poles: (Dimensions) | 4 |
| Pollution Degree: (Dimensions) | 3 |
| CB Certificate: (Environmental) | 1SAA920005-2001 |
| ETIM 5: (Container Information) | EC001653 - Installation contactor for distribution board |
| ETIM 6: (Container Information) | EC001653 - Installation contactor for distribution board |
| ETIM 7: (Container Information) | EC001653 - Installation contactor for distribution board |
| NF Certificate: (Environmental) | 1SAA920001-1202 |
| RoHS Status: (Technical UL/CSA) | Following EU Directive 2011/65/EU |
| Tightening Torque: (Dimensions) | Control Circuit 0.9 N·mMain Circuit 2,5 N·m |
| UNSPSC: (Container Information) | 39121529 |
| eClass: (Container Information) | 7.0 27142308 |
| CCC Certificate: (Environmental) | 1SAA920003-3801 |
| DNV Certificate: (Environmental) | 1SAA920000-0306 |
| EAC Certificate: (Environmental) | 1SAA920001-2702 |
| RMRS Certificate: (Environmental) | 1SAA920000-0705 |
| Rated Frequency (f): (Dimensions) | Control Circuit 400 HzControl Circuit 50 HzControl Circuit 60 HzControl Circuit DCMain Circuit 50 HzMain Circuit 60 HzMain Circuit DC |
| RoHS Information: (Environmental) | 1SAD938503-0302 |
| Degree of Protection: (Dimensions) | IP20 |
| cULus Certificate: (Environmental) | cUL_E191658 |
| Electrical Durability: (Dimensions) | AC-1 (NO) 100000 cycleAC-3 (NO) 240000 cycleAC-7a (NO) 100000 cycleAC-7b (NO) 240000 cycle |
| Mechanical Durability: (Dimensions) | 1000000 cycle |
| Wire Stripping Length: (Dimensions) | Control Circuit 7 mmMain Circuit 13 mm |
| Instructions and Manuals: (Ordering) | 2CDC103043M6801 |
| Horsepower Rating UL/CSA: (Technical) | (220 ... 240 V AC) Single Phase, NO 5 Hp(220 ... 240 V AC) Three Phase, NO 10 Hp(440 ... 480 V AC) Single Phase, NO 7.5 Hp(440 ... 480 V AC) Three Phase, NO 15 Hp |
| Tightening Torque UL/CSA: (Technical) | Control Circuit 8 in·lbMain Circuit 20 in·lb |
| Product Net Width: (Popular Downloads) | 54 mm |
| Recommended Screw Driver: (Dimensions) | Control Circuit Pozidriv 1Main Circuit Pozidriv 2 |
| Product Net Height: (Popular Downloads) | 85 mm |
| Product Net Weight: (Popular Downloads) | 0.405 kg |
| Rated Operational Voltage: (Dimensions) | Main Circuit 220 V DCMain Circuit 400 V AC |
| Number of Main Contacts NC: (Dimensions) | 0 |
| Number of Main Contacts NO: (Dimensions) | 4 |
| Instructions and Manuals: (Environmental) | 2CDC103043M6801 |
| E-Number (Sweden): (Container Information) | 3210572 |
| Ambient Air Temperature: (Technical UL/CSA) | Operation -25 ... +55 °CStorage -40 ... +80 °C |
| Rated Insulation Voltage (Ui): (Dimensions) | acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 500 V |
| Maximum Operating Voltage UL/CSA: (Technical) | Main Circuit 480 V AC |
| Connecting Capacity Main Circuit: (Dimensions) | Flexible with Ferrule 1x 1.5 ... 16 mm²Flexible with Ferrule 2x 1.5 ... 10 mm²Flexible with Insulated Ferrule 1x 1.5 ... 16 mm²Flexible with Insulated Ferrule 2x 1.5 ... 10 mm²Flexible 1x 1.5 ... 16 mm²Flexible 2x 1.5 ... 10 mm²Rigid 1x 1.5 ... 25 mm²Rigid 2x 1.5 ... 10 mm² |
| Declaration of Conformity - CE: (Environmental) | 1SAD938503-0302 |
| Product Net Depth / Length: (Popular Downloads) | 65 mm |
| Rated Operational Power AC-1 (Pe): (Dimensions) | (230 V) Single Phase, NO 14.5 kW(400 V) Three Phase, NO 43.6 kW |
| Rated Operational Power AC-3 (Pe): (Dimensions) | (230 V) Single Phase, NO 5 kW(400 V) Three Phase, NO 15 kW |
| Rated Control Circuit Voltage (Uc): (Dimensions) | 24 V |
| Rated Operational Power AC-7a (Pe): (Dimensions) | (230 V) Single Phase, NO 14.5 kW(400 V) Three Phase, NO 43.6 kW |
| Rated Operational Power AC-7b (Pe): (Dimensions) | (230 V) Single Phase, NO 5 kW(400 V) Three Phase, NO 15 kW |
| Connecting Capacity Control Circuit: (Dimensions) | Flexible with Ferrule 1x 1 ... 2.5 mm²Flexible with Ferrule 2x 0.75 ... 1.5 mm²Flexible with Insulated Ferrule 1x 1 ... 2.5 mm²Flexible with Insulated Ferrule 2x 0.75 ... 1 mm²Flexible 1x 1 ... 2.5 mm²Flexible 2x 1 ... 1.5 mm²Rigid 1x 1 ... 4 mm²Rigid 2x 1 ... 2.5 mm² |
| Rated Operational Current AC-1 (Ie): (Dimensions) | (NO) 63 A |
| Rated Operational Current AC-3 (Ie): (Dimensions) | (230 V) Single Phase, NO 30 A(400 V) Three Phase, NO 30 A |
| Width in Number of Modular Spacings: (Dimensions) | 3 |
| Rated Operational Current AC-7a (Ie): (Dimensions) | (NO) 63 A |
| Rated Operational Current AC-7b (Ie): (Dimensions) | (230 V) Single Phase, NO 30 A(400 V) Three Phase, NO 30 A |
| Object Classification Code: (Container Information) | Q |
| Connecting Capacity Main Circuit UL/CSA: (Technical) | Solid 16-4 AWGStranded 16-4 AWG |
| Rated Impulse Withstand Voltage (Uimp): (Dimensions) | 6 kV |
| Connecting Capacity Control Circuit UL/CSA: (Technical) | Solid 16-10 AWGStranded 16-10 AWG |
| Maximum Operating Altitude Permissible: (Technical UL/CSA) | 2000 m |
| Resistance to Shock acc. to IEC 60068-2-27: (Technical UL/CSA) | 11 ms Pulse 15g |
| Package Level 2 EAN: (Certificates and Declarations (Document Number)) | 4013614539671 |
| Package Level 1 Units: (Certificates and Declarations (Document Number)) | 1 piece |
| Package Level 1 Width: (Certificates and Declarations (Document Number)) | 57 mm |
| Package Level 2 Units: (Certificates and Declarations (Document Number)) | 40 piece |
| Package Level 2 Width: (Certificates and Declarations (Document Number)) | 280 mm |
| Package Level 1 Height: (Certificates and Declarations (Document Number)) | 92 mm |
| Package Level 2 Height: (Certificates and Declarations (Document Number)) | 210 mm |
| Package Level 1 Gross Weight: (Certificates and Declarations (Document Number)) | 0.405 kg |
| Package Level 1 Depth / Length: (Certificates and Declarations (Document Number)) | 69.5 mm |
| Package Level 2 Depth / Length: (Certificates and Declarations (Document Number)) | 395 mm |
