In Stock Hot Product
084Z7269
084Z7269 DANFOSS CONTROLES INDUSTRIALES Temperature sensor, MBT 3270
$0.00USD
4930 in stock
Key Specifications
EAN:5702423200993
Net weight:0.03 Kg
Wires [pcs]:2 pc
Gross weight:0.03 Kg
Supplier Information
DANFOSS INDUSTRIAL AUTOMATION
Products: 1269
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702423200993 |
| Net weight | 0.03 Kg |
| Wires [pcs] | 2 pc |
| Gross weight | 0.03 Kg |
| Product name | Temperature sensor |
| Product type | MBT 3270 |
| Output signal | Ohm |
| Product Group | CETOP 3 BLOCK |
| Sensor Insert | Fixed |
| Insertion type | Fixed |
| Packing format | Multi pack |
| Connection type | M |
| Type designation | MBT 3270-0A150-037-30300-000 |
| Connection material | Brass |
| Enclosure rating IP | IP67 |
| Process Connections | M10x1ISO 965 |
| Sensor element [pc] | 1 pc |
| Sensor element type | NTC |
| Electrical connection | AMP |
| Insertion length [in] | 1.46 in |
| Insertion length [mm] | 37 mm |
| Process connection size | 10x1 |
| Process connection type | M |
| Protection tube material | Brass |
| Sensor element tolerance | ± 1% |
| Electrical conn. comments | Integrated |
| Electrical connection size | 2 pin |
| Process connection material | Brass |
| Process connection standard | ISO 965 |
| Quantity per packing format | 40 pc |
| Protection tube diameter [in] | 0.2 in |
| Protection tube diameter [mm] | 5 mm |
| Sensor elem. resistance [Ohm] | 3000 Ohm |
| Temperature range [°C] [Max] | 150 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 302 °F |
| Temperature range [°F] [Min] | -58 °F |
| Ambient temperature max. [°C] | 125 °C |
| Ambient temperature max. [°F] | 257 °F |
| Process connection Male/Female | Male |
Product Description
Temperature sensor, MBT 3270, 37 mm, M,10x1
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
