067N4166
067N4166 DANFOSS REFRIGERATION Thermostatic expansion valve, TGE
$0.00USD
4185 in stock
Key Specifications
EAN:5702428167475
Approval:C UL US LISTEDEACLLC CDC TYSK
Direction:Straightway
Net weight:1.01 Kg
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702428167475 |
| Approval | C UL US LISTEDEACLLC CDC TYSK |
| Direction | Straightway |
| Net weight | 1.01 Kg |
| Serviceable | No |
| Gross weight | 1.12 Kg |
| Orifice size | 26 |
| Product name | Thermostatic expansion valve |
| Product type | TGE |
| Refrigerants | R407C |
| Body material | Brass |
| Product Group | Expansion valves |
| Flow direction | Bi-flow |
| Packing format | Multi pack |
| Parts included | Bulb strap |
| Inlet size [in] | 1 1/8 IN |
| Outlet size [in] | 1 3/8 IN |
| Identical product | 067N4186 |
| Superheat setting | Adjustable |
| Connection material | Copper |
| Product accessories | TXV accessories |
| Product description | Thermostatic Expans. Valve |
| Product family name | TGE |
| Inlet connection type | SOLDER, ODF |
| Pressure equalization | Externally equalized |
| Balanced port [Yes/No] | Yes |
| Equalization size [in] | 1/4 IN |
| Outlet connection type | SOLDER, ODF |
| Orifice capacities [TR] | 24 tons |
| Orifice capacities [kW] | 84 kW |
| System line application | Liquid line |
| Flow direction indicator | Embossed 1-way arrow |
| Capillary tube length [in] | 118 in |
| Capillary tube length [mm] | 3000 mm |
| Bulb temperature max. [ºC] | 100 °C |
| Bulb temperature max. [ºF] | 210 °F |
| Max. Working Pressure [bar] | 46 bar |
| Quantity per packing format | 6 pc |
| Static Superheat (SS) [°C] | 4 °C |
| Static Superheat (SS) [°F] | 7.2 °F |
| Valve body temp. max. [°C] | 100 °C |
| Valve body temp. max. [°F] | 210 °F |
| Equalization connection type | SOLDER, ODF |
| Max. Working Pressure [psig] | 667 psig |
| Rated cap. cond. Range N [SI] | tcond=38 °Ctevap=4.4 °Ctliq=37 °C |
| Temperature range [°C] [Max] | 10 °C |
| Temperature range [°C] [Min] | -40 °C |
| Temperature range [°F] [Max] | 50 °F |
| Temperature range [°F] [Min] | -40 °F |
| Element temperature max. [°C] | 110 °C |
| Element temperature max. [°F] | 230 °F |
| Rated cap. cond. Range N [IMP] | tcond=100 °Ftevap=40 °Ftliq=98 °F |
