065F0114
065F0114 DANFOSS HEATING VMT PN10 15/2,8 2-way/2 ext.thr Straight
$0.00USD
4023 in stock
Key Specifications
EAN ():5702421300503
Type ():VMT
Volume ():0.393 Liter
Function ():Control valve
Supplier Information
DANFOSS HEATING
Products: 5013
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN () | 5702421300503 |
| Type () | VMT |
| Volume () | 0.393 Liter |
| Function () | Control valve |
| Net weight () | 0.369 Kilogram |
| Valve size () | DN 15 |
| Application () | Heating and cooling |
| Description () | VMT PN10 15/2,8 2-way/2 ext.thr Straight |
| Stroke [mm] () | 1.1 mm |
| Gross weight () | 0.369 Kilogram |
| Diameter [mm] () | 15 mm |
| Product group () | Motorized control valves |
| Media pH [Max] () | 10 |
| Media pH [Min] () | 7 |
| Pressure class () | PN 10 |
| Connection size () | G 3/4 A |
| Number of ports () | 2 |
| Connection types () | External Thread |
| Mounting version () | Free |
| Spindle position () | Normally open |
| Cavitation factor () | 0.5 |
| Permissible media () | District heating/cooling circulation water |
| EU RoHS compliance () | Yes with exemptions |
| Medium alternative () | Glycolic water up to 30% |
| PN alternative VSP () | 6 |
| Flow characteristic () | Linear |
| Valve body material () | Brass W. No 2.0402 |
| Valve cone material () | NBR rubber |
| Pressure nominal [bar] () | 10 bar |
| EU RoHS exemption clause () | 6(c) |
| Media temperature [°C] [Max] () | 120 °C |
| Media temperature [°C] [Min] () | 2 °C |
| REACH Candidate List substances () | Lead (CAS no. 7439-92-1) |
| In scope of WEEE and contain batteries () | No |
| Differential pressure range [bar] [Max] () | 0.2 bar |
Product Description
VMT, PN 10, DN 15, External Thread, G 3/4 A
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
VMT PN10 15/2,8 2-way/2 ext.thr Straight
