060H1505
060H1505 DANFOSS REFRIGERATION Thermostat UT72
$0.00USD
4001 in stock
Key Specifications
EAN:5702428529679
Approval:CEEACEMCDLVDRoHSRoHS ChinaTYSK
Net weight:0.24 Kg
Serviceable:No
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702428529679 |
| Approval | CEEACEMCDLVDRoHSRoHS ChinaTYSK |
| Net weight | 0.24 Kg |
| Serviceable | No |
| Gross weight | 0.25 Kg |
| Product name | Thermostat |
| Product type | UT 72 |
| Product Group | Switches and thermostats |
| Contact rating | AC15=1 A, 250 VAC1=16 A, 250 V |
| Packing format | Multi pack |
| Reset function | Auto |
| Mounting method | Wall |
| Contact function | SPDT |
| Enclosure rating IP | IP20 |
| Product accessories | UT accessories |
| Differential (FS) [K] | 2.3 K |
| Electrical connection | Clamps Terminal screws |
| Capillary tube material | Copper |
| Sensor size (Ø x L) [in] | 15/64 x 4 44/64 in |
| Sensor size (Ø x L) [mm] | 6 x 119 mm |
| Capillary tube length [mm] | 3000 mm |
| Quantity per packing format | 24 pc |
| Max. sensor temperature [°C] | 60 °C |
| Max. sensor temperature [°F] | 140 °F |
| Temperature range [°C] [Max] | 30 °C |
| Temperature range [°C] [Min] | -30 °C |
| Temperature range [°F] [Max] | 85 °F |
| Temperature range [°F] [Min] | -22 °F |
| Ambient temperature range [°C] [Max] | 55 °C |
| Ambient temperature range [°C] [Min] | -30 °C |
| Ambient temperature range [°F] [Max] | 130 °F |
| Ambient temperature range [°F] [Min] | -22 °F |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
