060-110366
060-110366 DANFOSS REFRIGERATION Pressure switch
$0.00USD
4988 in stock
Key Specifications
EAN:5702422017486
Approval:BVCCCCEDNVEACGLLRLVDPEDPZHRINARMRSRoHS Chinac UL us UL353, CS C22.2c UL us UL873, CS C22.2
Net weight:0.29 Kg
Serviceable:No
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702422017486 |
| Approval | BVCCCCEDNVEACGLLRLVDPEDPZHRINARMRSRoHS Chinac UL us UL353, CS C22.2c UL us UL873, CS C22.2 |
| Net weight | 0.29 Kg |
| Serviceable | No |
| Gross weight | 0.32 Kg |
| Product name | Pressure switch |
| Product type | KP1 |
| Refrigerants | R113R124R134aR22R404AR407AR407CR407FR407HR422BR422DR438AR448AR449AR450AR452AR507AR513A |
| Product Group | Switches and thermostats |
| Contact rating | AC15=10 A, 400 VAC1=16 A, 400 VAC3=16 A, 400 VDC13=12 W, 220 VLR=112 A, 400 V |
| Packing format | Multi pack |
| Reset function | Manual Min |
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Contact function | SPDT |
| Regulation range | 27 inHg - 101 psig |
| Differential [bar] | 0.7 bar |
| Differential [psi] | 10 psi |
| Enclosure rating IP | IP30 |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP Pressure switch |
| Pressure Male/Female | Male |
| Electrical connection | Rubber cable gland |
| UL approval file name | E31024MH27572 |
| Pressure range category | Low pressure |
| Pressure connection size | 1/4 |
| Pressure connection type | Flare |
| Pressure sensing element | Bellows |
| Enclosure rating Nema (~) | 1 |
| Max. test pressure [psig] | 290 psig |
| EN 60947 wiring properties | Flex, ferrules: 0.5-1.5 mm2Flex, no ferrules: 0.7-2.5 mm2Solid/stranded: 0.75-2.5 mm2 |
| Electrical connection size | 6-14 mm |
| Max. Working Pressure [bar] | 17 bar |
| Max. test pressure [bar] Pe | 20 bar |
| Quantity per packing format | 36 pc |
| Max. Working Pressure [psig] | 245 psig |
| Pressure connection standard | DIN 8906 |
| EN 60947 electrical properties | Insulation: 400VPollution degree: 3Rated impulse voltage: 4 kV |
| Regulation range [bar] Pe [Max] | 7 bar |
| Regulation range [bar] Pe [Min] | -0.9 bar |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -25 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -13 °F |
Product Description
KP1 Pressure Switch M/36
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
