In Stock Hot Product
047H3033
047H3033 DANFOSS CONTROLES INDUSTRIALES Overload relay
$0.00USD
3492 in stock
Key Specifications
EAN:5702423088829
Approval:CEEACLLC CDC TYSKUL
Function:MANUAL RESET
Net weight:5.37 Kg
Supplier Information
DANFOSS INDUSTRIAL AUTOMATION
Products: 1269
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702423088829 |
| Approval | CEEACLLC CDC TYSKUL |
| Function | MANUAL RESET |
| Net weight | 5.37 Kg |
| Gross weight | 5.54 Kg |
| Product name | Overload relay |
| Product type | TI 630 E |
| Product Group | Contactors and motor starters |
| Packing format | Multi pack |
| Product description | Elec.Motor Protection Relay |
| UL approval file name | E82701 |
| Current range [A] [Max] | 630 A |
| Current range [A] [Min] | 160 A |
| Quantity per packing format | 2 pc |
| Coil voltage @ 50/60 Hz [Max] | 230 V |
| Coil voltage @ 50/60 Hz [Min] | 220 V |
| Control voltage, 50/60 Hz [V] [Max] | 230 V |
| Control voltage, 50/60 Hz [V] [Min] | 220 V |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
