042N8652
042N8652 DANFOSS REFRIGERATION Solenoid coil, AU240CS
$0.00USD
3244 in stock
Key Specifications
EAN ():5702423211968
Type ():AU240CS
Colour ():Blue
Volume ():0.562 Liter
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN () | 5702423211968 |
| Type () | AU240CS |
| Colour () | Blue |
| Volume () | 0.562 Liter |
| Approval () | LLC CDC TYSK |
| Compliance () | EN 60730-1 |
| Net weight () | 0.178 Kg |
| Serviceable () | No |
| Gross weight () | 0.191 Kg |
| Actuator size () | 9 mm |
| Product group () | Solenoid valves |
| Coil fastening () | Clip-on |
| Frequency [Hz] () | 50/60 Hz |
| Packing format () | Industrial pack |
| Coil connection () | Cable |
| Cable length [m] () | 1 m |
| Type designation () | AU240CS |
| Cable length [in] () | 40 in |
| Spare part number () | 042N7652 |
| Parts Program name () | EV220W |
| Enclosure rating IP () | IP67 |
| Product accessories () | Solenoid coil accessories |
| Conductor area [mm2] () | 3 x 0.75 mm2 |
| Electrical connector () | 3 core cable |
| Electrical connection () | Cable |
| Supply voltage [V] AC () | 240 V |
| Product Name Description () | Solenoid coil |
| Power consumption [W] 50Hz () | 6.5 W |
| Power consumption [W] 60Hz () | 5 W |
| Rel. Humidity [% RH] [max] () | 100 % |
| Rel. Humidity [% RH] [min] () | 0 % |
| Power consumption 50Hz [VA] () | 13 VA |
| Power consumption 60Hz [VA] () | 10 VA |
| Quantity per packing format () | 20 pc |
| Supply voltage 50Hz Max [V] () | 240 V |
| Supply voltage 60Hz Max [V] () | 240 V |
| REACH Candidate List substances () | No |
| Ambient temperature range [°C] [max] () | 60 °C |
| Ambient temperature range [°C] [min] () | -40 °C |
| Ambient temperature range [°F] [max] () | 140 °F |
| Ambient temperature range [°F] [min] () | -40 °F |
| In scope of WEEE and contain batteries () | No |
Product Description
Solenoid coil, AU240CS, Cable, 1.00 m, Supply voltage [V] AC: 240, Industrial pack
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Electrical connection: Cable, Supply voltage [V] AC: 240, Frequency [Hz]: 50/60 Hz, Enclosure rating IP: IP67
