In Stock Hot Product
042N7697
042N7697 DANFOSS REFRIGERATION Solenoid coil, AU024DS
$0.00USD
4175 in stock
Key Specifications
EAN ():5702428044868
Type ():AU024DS
Colour ():Blue
Volume ():0.878 Liter
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN () | 5702428044868 |
| Type () | AU024DS |
| Colour () | Blue |
| Volume () | 0.878 Liter |
| Approval () | LLC CDC TYSK |
| Compliance () | EN 60730-1 |
| Net weight () | 0.173 Kg |
| Serviceable () | No |
| Gross weight () | 0.23 Kg |
| Actuator size () | 9 mm |
| Product group () | Solenoid valves |
| Coil fastening () | Clip-on |
| Packing format () | Multi pack |
| Coil connection () | Cable |
| Cable length [m] () | 1 m |
| Type designation () | AU024DS |
| Cable length [in] () | 40 in |
| Identical product () | 042N8697 |
| Spare part number () | 042N7697 |
| EU RoHS compliance () | No - out of scope |
| Parts Program name () | EV220W |
| Enclosure rating IP () | IP67 |
| Product accessories () | Solenoid coil accessories |
| Conductor area [mm2] () | 3 x 0.75 mm2 |
| Electrical connector () | 3 core cable |
| Electrical connection () | Cable |
| Supply voltage [V] DC () | 24 V |
| Power consumption [W] DC () | 14 W |
| Product Name Description () | Solenoid coil |
| Rel. Humidity [% RH] [max] () | 100 % |
| Rel. Humidity [% RH] [min] () | 0 % |
| Quantity per packing format () | 24 pc |
| REACH Candidate List substances () | No |
| Ambient temperature range [°C] [max] () | 50 °C |
| Ambient temperature range [°C] [min] () | -40 °C |
| Ambient temperature range [°F] [max] () | 122 °F |
| Ambient temperature range [°F] [min] () | -40 °F |
| In scope of WEEE and contain batteries () | No |
Product Description
Solenoid coil, AU024DS, Cable, 1.00 m, Multi pack
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Solenoid coil, Product Type: AU024DS, Supply voltage [V] DC: 24, Enclosure rating IP: IP67, Coil connection: Cable, Actuator size: 9 mm
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
