042H2028
042H2028 DANFOSS REFRIGERATION Electric expansion valve
$0.00USD
3122 in stock
Key Specifications
EAN:5702422111238
Coil:No
Approval:EACLLC CDC TYSK
Function:NC
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702422111238 |
| Coil | No |
| Approval | EACLLC CDC TYSK |
| Function | NC |
| Direction | Straightway |
| Net weight | 4.34 Kg |
| Gross weight | 4.7 Kg |
| MinODP [bar] | 0 bar |
| MinODP [psi] | 0 psi |
| Product name | Electric expansion valve |
| Product type | AKV 20-4 |
| Refrigerants | R134aR22/R407CR23R404A/R507R407AR407FR410AR422BR422DR448AR449AR449BR450AR452AR513AR744 |
| MOPD[bar/psi] | 18 BAR |
| Product Group | Expansion valves |
| Packing format | Single pack |
| Inlet size [in] | 1 1/2 IN |
| Kv value [m³/h] | 4 m3/h |
| Outlet size [in] | 1 1/2 IN |
| Type designation | Electric expansion valve |
| Orifice size [mm] | 14 mm |
| Cv value [gal/min] | 4.624 gal/min |
| MaxOPD[bar] 10W AC | 18 bar |
| MaxOPD[psi] 10W AC | 260 psi |
| Ambient temperature | -40 - 50 °C |
| Product family name | AKV |
| Actuator system [mm] | 13.5 mm |
| Inlet connection type | Weld connection |
| Outlet connection type | Weld connection |
| Manual operation option | No |
| Rated capacity R22 [kW] | 400 kW |
| System line application | Liquid feed lineLiquid lineSuction lineWet return line |
| Max. Working Pressure [bar] | 28 bar |
| Quantity per packing format | 1 pc |
| Max. Working Pressure [psig] | 400 psig |
| Medium temperature range [°C] [Max] | 60 °C |
| Medium temperature range [°C] [Min] | -40 °C |
| Medium temperature range [°F] [Max] | 140 °F |
| Medium temperature range [°F] [Min] | -40 °F |
| Ambient temperature range [°F] [Max] | 120 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
Product Description
AKV20-4 Valve Weld con. 1 1/2in Singlep.
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
