034G5055
034G5055 DANFOSS REFRIGERATION Electric expansion valve
$0.00USD
4881 in stock
Key Specifications
EAN ():5702428825498
Type ():ETS 6 - 32
Volume ():0.491 Liter
Approval ():CECQCEACLLC CDC TYSKRoHSULUKCA
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN () | 5702428825498 |
| Type () | ETS 6 - 32 |
| Volume () | 0.491 Liter |
| Approval () | CECQCEACLLC CDC TYSKRoHSULUKCA |
| Direction () | Angleway |
| Step mode () | 2-phase full stepHalf step (recommended)Microstep |
| Motor type () | Permanent magnet stepper motor |
| Net weight () | 0.048 Kg |
| Fluid Group () | 2 |
| Serviceable () | No |
| Total steps () | 480 (half steps) |
| Gross weight () | 0.078 Kg |
| MaxOPD [bar] () | 28 bar |
| PED category () | Art. 3, par. 3 |
| Refrigerants () | R134aR22/R407CR410AR290R32R448AR449AR452AR1234yfR407HR449BR452BR454AR454BR454CR455AR463AR513AR404A/R507A |
| MOPD[bar/psi] () | 28 bar |
| MaxOPD [psig] () | 406 psig |
| Product group () | Expansion valves |
| Flow direction () | Bi-flow |
| Packing format () | Multi pack |
| Connection type () | Solder, ODF |
| Inlet size [in] () | 5/16 in |
| Inlet size [mm] () | 7.94 mm |
| Outlet size [in] () | 5/16 in |
| Outlet size [mm] () | 7.94 mm |
| Identical product () | 034G5050 |
| Orifice size [mm] () | 3.2 mm |
| EU RoHS compliance () | Yes |
| Parts Program name () | ETS 6 |
| Connection material () | Copper |
| Product accessories () | Electric valve accessories |
| Manual operation option () | AST-G service driverETS 6 Manual coil |
| Rated capacity R22 [TR] () | 8.19 TR |
| Rated capacity R22 [kW] () | 28.8 kW |
| Lubricants compatibility () | MOPOE |
| Product Name Description () | Electric expansion valve |
| UL approved refrigerants () | R134aR22R404AR407CR410AR448AR449AR452AR507A |
| Rated capacity R134a [TR] () | 6.4 TR |
| Rated capacity R134a [kW] () | 22.5 kW |
| Rated capacity R407C [TR] () | 8.42 TR |
| Rated capacity R407C [kW] () | 29.6 kW |
| Rated capacity R410A [TR] () | 9.64 TR |
| Rated capacity R410A [kW] () | 33.9 kW |
| Rated cap. conditions [SI] () | Subcooling=0 ºCSuperheat=0 ºCtcond=38 ºCtevap=5 ºC |
| Max. Working Pressure [bar] () | 47 bar |
| Quantity per packing format () | 10 pc |
| Rated cap. R404A/R507A [TR] () | 5.77 TR |
| Rated cap. R404A/R507A [kW] () | 20.3 kW |
| Rated cap. conditions [IMP] () | Subcooling=32 ºFSuperheat=32 ºFtcond=100 ºFtevap=41 ºF |
| Max. Working Pressure [psig] () | 681 psig |
| Compatible Danfoss controllers () | EIM 336EKE 1AEKE 1BEKE 1C |
| REACH Candidate List substances () | No |
| Full travel time speed [s] [max] () | 16 s |
| Full travel time speed [s] [min] () | 6 s |
| Refrigerant temperature [ºC] [max] () | 70 °C |
| Refrigerant temperature [ºC] [min] () | -30 °C |
| Refrigerant temperature [ºF] [max] () | 158 °F |
| Refrigerant temperature [ºF] [min] () | -22 °F |
| Ambient temperature range [°C] [max] () | 70 °C |
| Ambient temperature range [°C] [min] () | -30 °C |
| Ambient temperature range [°F] [max] () | 158 °F |
| Ambient temperature range [°F] [min] () | -22 °F |
| In scope of WEEE and contain batteries () | No |
Product Description
ETS 6-32 Electric exp. valve
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Inlet size [in]: 5/16 in, Outlet size [in]: 5/16 in
