In Stock Hot Product
032F1217
032F1217 DANFOSS REFRIGERATION EVR 10 Valve ODF-ODF 1/2in Multi 12
$0.00USD
4246 in stock
Key Specifications
MCC:38 A
RLA:24.3 A
Region:Africa; Asia; Middle East; Pacific
Version:W02
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| MCC | 38 A |
| RLA | 24.3 A |
| Region | Africa; Asia; Middle East; Pacific |
| Version | W02 |
| Type Code | Optyma™ Slim Pack |
| Net weight | 99.00 Kg |
| Technology | Scroll |
| Width [mm] | 1106 |
| Length [mm] | 464 |
| Refrigerant | R134a; R22; R404A; R507 |
| Applications | MBP |
| Gross weight | 117.00 Kg |
| Model number | OP-MPUE080MLW02G |
| • Receiver | 118U3476 |
| Segment usage | Medium Back Pressure |
| • Condenser | 118U3494 |
| • Fan blade | 118U3768 |
| • Fan motor | 118U3767 |
| Condenser type | G7 |
| Number of fans | 1 |
| • Compressor | 121U8034 |
| Electrical code | G |
| • Sight glass | 014L0203 |
| Compressor model | MLZ038T5 |
| Type designation | Condensing Units |
| Voltage 50Hz [V] | 220 |
| • Filter drier | 023Z5044 |
| • Liquid valve | 118U3757 |
| Approval standard | CE |
| Fan diameter [mm] | 600 |
| Receiver approval | CE |
| Total height [mm] | 830 |
| • Run capacitor | 8173234 |
| • Suction valve | 118U3760 |
| • Fan cowl/grill | 118U3485 |
| • Solenoid valve | 032F1217 |
| • Starting relay | 120Z0395 |
| Fan blade size [mm] | 600 |
| Fan cowl/grill type | B3 |
| No. of phases (fan) | 1 |
| Receiver volume [L] | 6.2 |
| • Sheet metal fan | 118U5152 |
| • Sheet metal top | 118U5151 |
| • Sheet metal back | 118U5153 |
| • Sheet metal left | 118U5169 |
| Fan current @ 50Hz [A] | 3 |
| Voltage 50Hz [V] [Max] | 240 |
| • Starting capacitor | 8173001 |
| Air flow @ 50Hz [m³/h] | 8700 |
| Suction connection type | Solder |
| • Dual pressure switch | 8173234 |
| • Receiver Description | 6,2L |
| • Condenser Description | G7 |
| • Fan blade Description | Fan blade |
| • Fan motor Description | Fan motor |
| Fan power supply [V/Ph/Hz] | 230/1/50 |
| No. of phases (compressor) | 1 |
| Sound power @ 50Hz [db(A)] | 70 |
| • Compressor Description | MLZ038T5 |
| Fan power output @ 50Hz [W] | 370 |
| Liquid line connection [in] | 1/2 |
| Liquid line connection type | Solder |
| Suction connection size [in] | 7/8 |
| • Liquid valve Description | Valve Suction |
| • Run capacitor Description | Run capacitor 440V,55 µF |
| • Sheet metal service panel | 118U5154 |
| • Fan cowl/grill Description | ø 609 mm |
| • Starting relay Description | Starting relay type RVA4GKL/3ARR3J25S4 |
| • Sheet metal fan Description | Sheet Metal Fan B3 |
| • Sheet metal top Description | Sheet Metal Top B3 |
| Fan power consumption @ 50Hz [W] | 665 |
| • Sheet metal back Description | Sheet Metal Back B3 |
| • Sheet metal left Description | Sheet Metal Left Side B3 |
| Compressor power supply [V/Ph/Hz] | 230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] | 230 |
| Fan voltage @ 50Hz (max) [V] [Min] | 230 |
| • Starting capacitor Description | Start capacitor 330V, 98 µF |
| • Dual pressure switch Description | Run capacitor 440V,55 µF |
| • Sheet metal service panel Description | Sheet Metal Service Panel B3 |
| Sound pressure level 50Hz (@1 m distance) [db(A)] | 59 |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
