In Stock Hot Product
030F8704
030F8704 DANFOSS HEATING Nozzle 0.40 gph 80° S LE
$0.00USD
3023 in stock
Key Specifications
CEN ():No
EAN ():5702425018428
Type ():LE
Shape ():Conical
Supplier Information
DANFOSS HEATING
Products: 5013
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| CEN () | No |
| EAN () | 5702425018428 |
| Type () | LE |
| Shape () | Conical |
| Volume () | 0.024 Liter |
| Approval () | CE |
| Net weight () | 0.034 Kilogram |
| Description () | 0.40GAL 80S LE |
| Filter type () | Sinter |
| CE evaluated () | Yes |
| Gross weight () | 0.035 Kilogram |
| UL evaluated () | Out of scope |
| Material type () | Brass |
| Product group () | Oil Nozzles |
| Spray pattern () | Solid |
| Capacity [l/h] () | 0 L/h |
| Packing format () | Industrial pack |
| Capacity [kg/h] () | 1.46 kg/h |
| Reference point () | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. () | 2e5b5d5c-a225-4f44-9a73-5b44abae4fe7 |
| Spray angle [°] () | 80 ° |
| Capacity [USgal/h] () | 0.4 gal/h |
| EU RoHS compliance () | Yes with exemptions |
| Filter grade [µm] () | 30 |
| LE anti-drip valve () | Yes |
| UK RoHS compliance () | Yes with exemptions |
| Specification point () | 11.6 bar, 3.4 cSt, 840 kg/m³ |
| China RoHS compliance () | Out of scope |
| spray pattern marking () | S |
| EU RoHS exemption clause () | 6(a)6(a)-I6(c) |
| UK RoHS exemption clause () | 1218 |
| SCIP dossier product name () | LE Nozzles 0.40-1.75 gph |
| Quantity per packing format () | 10 pc |
| REACH Candidate List substances () | Lead (CAS no. 7439-92-1) |
| In scope of WEEE and contain batteries () | No |
Product Description
Oil Nozzles, LE, 0.40 gal/h, 1.46 kg/h, 80 °, Solid
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
0.40GAL 80S LE
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
