030F8318
030F8318 DANFOSS HEATING Nozzle 0.85 gph 80° ES
$0.00USD
4586 in stock
Key Specifications
CEN ():No
EAN ():5702425014000
Type ():ES
Shape ():Conical
Supplier Information
DANFOSS HEATING
Products: 5013
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| CEN () | No |
| EAN () | 5702425014000 |
| Type () | ES |
| Shape () | Conical |
| Volume () | 0.024 Liter |
| China RoHS () | Out of scope |
| Net weight () | 0.032 Kg |
| Description () | 0.85GAL 80ES |
| Filter type () | Sinter |
| Gross weight () | 0.033 Kg |
| Material type () | Brass |
| Product group () | Oil Nozzles |
| Spray pattern () | Solid |
| Capacity [l/h] () | 0 L/h |
| Packing format () | Industrial pack |
| Capacity [kg/h] () | 2.55 kg/h |
| Reference point () | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. () | 128fcc57-49a6-4de2-b90b-f71eda76684c |
| Spray angle [°] () | 80 ° |
| Capacity [USgal/h] () | 0.85 gal/h |
| EU RoHS compliance () | Yes with exemptions |
| Filter grade [µm] () | 45 |
| LE anti-drip valve () | No |
| Specification point () | 8.0 bar, 1.65 cSt, 790 kg/m³ |
| spray pattern marking () | ES |
| SCIP dossier product name () | 30 H F E - Nozzle 0.65-1.10 gph |
| Quantity per packing format () | 10 pc |
| REACH Candidate List substances () | Lead (CAS no. 7439-92-1) |
| In scope of WEEE and contain batteries () | No |
Product Description
Oil Nozzles, ES, 0.85 gal/h, 2.55 kg/h, 80 °, Solid
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
0.85GAL 80ES
