In Stock Hot Product
027B1080
027B1080 DANFOSS REFRIGERATION Pilot valve
$0.00USD
4224 in stock
Key Specifications
EAN ():5702428841160
Type ():CVC-LP
Volume ():6.248 Liter
Approval ():EACLLC CDC TYSKUL
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN () | 5702428841160 |
| Type () | CVC-LP |
| Volume () | 6.248 Liter |
| Approval () | EACLLC CDC TYSKUL |
| Function () | Constant pressure |
| Net weight () | 2.104 Kg |
| Fluid Group () | 1 |
| Serviceable () | Pilot valve spare parts |
| Gross weight () | 2.372 Kg |
| PED category () | Art. 3, par. 3 |
| Refrigerants () | R134aR22R401AR402AR404AR407AR407BR407CR407FR409AR410AR421AR502R717R744R507A |
| Product group () | Press. and temp. regul. valves |
| Valve version () | Low pressure |
| Packing format () | Single pack |
| Kv value [m³/h] () | 0.2 m³/h |
| Cv value [gal/min] () | 0.23 gal/min |
| EU RoHS compliance () | No - out of scope |
| Product accessories () | No |
| Product description () | Pressure-operated pilot valve |
| UL approval file name () | REFRIGERANT VALVE 53R0 |
| Product Name Description () | Pilot valve |
| Max. Working Pressure [bar] () | 28 bar |
| Quantity per packing format () | 1 pc |
| Max. Working Pressure [psig] () | 406 psig |
| Pressure range [bar] Pe [max] () | 9 bar |
| Pressure range [bar] Pe [min] () | -0.5 bar |
| Temperature range [°C] [max] () | 120 °C |
| Temperature range [°C] [min] () | -50 °C |
| Temperature range [°F] [max] () | 248 °F |
| Temperature range [°F] [min] () | -58 °F |
| REACH Candidate List substances () | Lead (CAS no. 7439-92-1) |
| In scope of WEEE and contain batteries () | No |
Product Description
Pilot valve, CVC-LP
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Technical Details
Function: Constant pressure, Cv value [gal/min]: 0.230
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
