021U0265
021U0265 DANFOSS REFRIGERATION Micro Channel heat exchanger, MCHE 25.4X2X20 DF0321 I/12
$0.00USD
3766 in stock
Key Specifications
EAN:5702428833547
Object:021U0265
Approval:EACPEDUL
Category:II
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702428833547 |
| Object | 021U0265 |
| Approval | EACPEDUL |
| Category | II |
| Net weight | 26.16 Kg |
| Fluid Group | II |
| Part Number | DF0321 |
| Serviceable | No |
| Gross weight | 42.17 Kg |
| Product name | Micro Channel heat exchanger |
| Product type | MCHE |
| Project Name | EAM STANDARD COIL D2000-C |
| Refrigerants | R410A |
| Body material | Aluminium |
| Product Group | Heat exchangers |
| Fin pitch [mm] | 1.1 mm |
| Flow direction | Single-flow |
| Packing format | Industrial pack |
| Coil depth [in] | 1 in |
| Coil depth [mm] | 25.4 mm |
| Inlet size [in] | 1 IN |
| Inlet size [mm] | 25.4 mm |
| Application area | Chiller |
| Coil Length [in] | 78.74 in |
| Coil Length [mm] | 2000 mm |
| Coil height [in] | 41.04 in |
| Coil height [mm] | 1042.3 mm |
| Outlet size [in] | 7/8 IN |
| Outlet size [mm] | 22.2 mm |
| Type designation | D2000-C |
| Identical product | 021U0264 |
| Approval file name | CE-0062-PED-H-DMC 001-17-CHNEAC RU С-DK.АД75.B.00162SA33862 |
| Connection material | Copper |
| Product accessories | No |
| Design pressure [MPa] | 4.5 MPa |
| Inlet connection type | SOLDER, ODF |
| Internal volume [cm3] | 5616 cm3 |
| Internal volume [in3] | 342.7 in3 |
| Mounting bar material | ALUMINIUM |
| Number of tubes [pcs] | 102 |
| Design pressure [psig] | 653 psig |
| Outlet connection type | SOLDER, ODF |
| Flow direction indicator | REFER TO MANUAL |
| Rated capacity R410A [TR] | 17.15 tons |
| Rated capacity R410A [kW] | 60.3 kW |
| Rated cap. conditions [SI] | Air speed=2.5 m/sAmbient temp.=35 °CDelta t=12 °CSubcooling=5 °C |
| Max. Working Pressure [bar] | 45 bar |
| Quantity per packing format | 12 pc |
| Rated cap. conditions [IMP] | Air speed=492 ft/minAmbient temp.=95 °FDelta t=21.6 °FSubcooling=9 °F |
| Max. Working Pressure [psig] | 650 psig |
| Temperature range [°C] [Max] | 121 °C |
| Temperature range [°C] [Min] | -40 °C |
| Temperature range [°F] [Max] | 250 °F |
| Temperature range [°F] [Min] | -40 °F |
| Operation Ambient Temp [°C] [Max] | 72 °C |
| Operation Ambient Temp [°C] [Min] | -40 °C |
| Operation Ambient Temp [°F] [Max] | 162 °F |
| Operation Ambient Temp [°F] [Min] | -40 °F |
Product Description
Microchannel heat exchanger, MCHE D2000-C, Industrial package
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
