021H9130
021H9130 DANFOSS REFRIGERATION Micro Plate heat exchanger H62L-CX-72
$0.00USD
4781 in stock
Key Specifications
Approval:EACLLC CDC EURO-TYSKPED
Code No.:021H9130
Function:Condenser
Equipment:Stud
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Approval | EACLLC CDC EURO-TYSKPED |
| Code No. | 021H9130 |
| Function | Condenser |
| Equipment | Stud |
| Model no. | 62 |
| Net weight | 12.86 Kg |
| Application | Heat pump application |
| Gross weight | 13.62 Kg |
| Product name | Micro Plate heat exchanger |
| Product type | MPHE |
| Refrigerants | R1233zdR1234zeR1270R1336mzz(Z)R134aR22R290R290AR32R404AR407AR407CR407FR410AR422BR422DR438AR444BR448AR449AR449BR450AR452AR454BR513AR513BR515AR600aR134a/R513AR454C |
| H1 conn. size | R1 1/2 |
| H1 conn. type | Solder connection |
| H2 conn. size | 1 1/8 in |
| H2 conn. type | Solder connection |
| H3 conn. size | 5/8 in |
| H3 conn. type | Solder connection |
| H4 conn. size | 5/8 in |
| H4 conn. type | Solder connection |
| Plate pattern | Asymmetric pattern, type X |
| Product Group | Heat exchangers |
| Packing format | Single pack |
| Plate material | AISI 316L |
| Brazing material | Copper brazing |
| Number of plates | 72 |
| Type designation | H62L-C |
| Max working pressure [psi] | 696 psi |
| Max. Working Pressure [bar] | 48 bar |
| Quantity per packing format | 1 pc |
| Design temperature range [°C] [Max] | 200 °C |
| Design temperature range [°C] [Min] | -196 °C |
| Design temperature range [°F] [Max] | 320 °F |
| Design temperature range [°F] [Min] | -390 °F |
Product Description
More details
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
