In Stock Hot Product
021H3602
021H3602 DANFOSS REFRIGERATION Micro Plate heat exchanger D55L-H-60 (STDPG)
$0.00USD
3472 in stock
Key Specifications
EAN:5702425085680
Approval:EACLLC CDC EURO-TYSKPEDUL
Code No.:021H3602
Equipment:Stud
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| EAN | 5702425085680 |
| Approval | EACLLC CDC EURO-TYSKPEDUL |
| Code No. | 021H3602 |
| Equipment | Stud |
| Model no. | 55 |
| Net weight | 11 Kg |
| Application | Universal application |
| Gross weight | 11.15 Kg |
| Product name | Micro Plate heat exchanger |
| Product type | MPHE |
| Refrigerants | R1233zdR1234zeR1336mzz(Z)R134aR22R290AR32R404AR407AR407CR407FR407HR410AR438AR444BR448AR449AR450AR452AR452BR454BR455AR513AR513BR515AR600a |
| H1 conn. size | R1 1/2 |
| Plate pattern | Symmetric pattern, type M |
| Product Group | Heat exchangers |
| Q1 conn. type | External thread connection |
| Q2 conn. type | External connection |
| Q3 conn. type | External connection |
| Q4 conn. type | G External thread connection |
| Packing format | Single pack |
| Plate material | AISI 316L |
| Brazing material | Copper brazing |
| Number of plates | 60 |
| Type designation | D55L |
| Q1 conn. size range | R1- 7/8 in |
| Q2 conn. size range | R1- 7/8 in |
| Q3 conn. size range | R1- 7/8 in |
| Q4 conn. size range | G1-H7/8 in |
| Max working pressure [psi] | 653 psi |
| Max. Working Pressure [bar] | 45 bar |
| Quantity per packing format | 1 pc |
| Design temperature range [°C] [Max] | 200 °C |
| Design temperature range [°C] [Min] | -196 °C |
| Design temperature range [°F] [Max] | 320 °F |
| Design temperature range [°F] [Min] | -390 °F |
Product Description
Heat Exchanger D55L-H-60 (STDPG)
Key Features
- Industrial grade quality
- RoHS compliant
- CE certified
- 1-year warranty
Product Documents
Datasheet
Technical specifications and performance data
User Manual
Installation and operation guide
