021H3363
021H3363 DANFOSS REFRIGERATION Brazed plate heat exchanger, BPHE B3-052-60 (30/14+14)-4.0-HQ
$0.00USD
3989 in stock
Key Specifications
Approval:EACLLC CDC EURO-TYSKPED
Code No.:021H3363
Model no.:052
Net weight:16.4 Kg
Supplier Information
DANFOSS REFRIGERATION
Products: 8639
Usually ships within 2-3 business days
Quality Guaranteed
Fast Shipping
Technical Support
Technical Specifications
| Parameter | Value |
|---|---|
| Approval | EACLLC CDC EURO-TYSKPED |
| Code No. | 021H3363 |
| Model no. | 052 |
| Net weight | 16.4 Kg |
| Gross weight | 16.7 Kg |
| Product name | Brazed plate heat exchanger |
| Product type | BPHE |
| Refrigerants | R1233zdR1234zeR1270R1336mzz(Z)R134aR22R290R290AR32R404AR407AR407CR407FR410AR422BR422DR438AR444BR448AR449AR449BR450AR452AR513AR513BR515AR600aR134a/R513AR125a |
| Function note | With distributor |
| H1 conn. size | R1 1/2 |
| H3 conn. size | 3/8 in |
| H3 conn. type | Solder connection |
| H4 conn. size | 3/4 in |
| H4 conn. type | Solder connection |
| Plate pattern | Symmetric pattern, type H |
| Product Group | Heat exchangers |
| Q1 conn. type | R External thread connection |
| Q2 conn. type | R External thread connection |
| Q3 conn. type | Solder connection |
| Q4 conn. type | Solder connection |
| Packing format | Single pack |
| Plate material | AISI 316L |
| Brazing material | Copper brazing |
| Number of plates | 60 |
| Type designation | B3-052-HQ |
| Q1 conn. size range | R1 |
| Q2 conn. size range | R1 |
| Q3 conn. size range | 3/8 in |
| Q4 conn. size range | 3/4 in |
| Max working pressure [psi] | 580 psi |
| Max. Working Pressure [bar] | 40 bar |
| Quantity per packing format | 1 pc |
| Design temperature range [°C] [Max] | 200 °C |
| Design temperature range [°C] [Min] | -196 °C |
| Design temperature range [°F] [Max] | 320 °F |
| Design temperature range [°F] [Min] | -390 °F |
